Model
|
Radius 270
|
|
SPECIFICATIONS
|
|
Frequency Response |
55 Hz ~ 25 KHz |
| Sensitivity (1W@1M) |
90 dB |
|
Impedance |
8 Ω |
| Power handling
Single (R.M.S) |
120 W |
|
System Power Handling
(R.M.S) |
140 W |
| Maximum SPL |
108 |
|
Recommended Amp Requirements |
40~140 |
| Bass Alignment |
Front Ported bass
reflex |
|
Drive unit Complement
Bass |
2 x 101mm(4")MMP@2
(Next generation Metal Matrix Polymer) |
| Drive unit complement
Tweeter |
1 x 25mm(1") C-CAM®
Gold Dome |
|
External Dimensions
(cm) |
61 H x 12 W x 10.5
D |
| External Dimensions
(inch) |
24 H x 4¾ W x
4⅛
D |
|
Individual Weight
(Kg) |
4.2 Kg |
| Individual Weight
(lb) |
9 ¼ lb |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
